高速空间光调制器
SLM-210
SLM-210采用了Santec 第二代液晶LCOS (Liquid Crystal on Silicon)技术，是一款高性能的空间光调制器。该型号大幅度提升了LCOS的响应速度。
SLM-210响应速度小于10ms，同比Santec以往型号提20倍以上，将显著改善光学应用性能，如波前校正、激光加工光束整形、生物传感和量子计算等。
特性
- 响应时间（典型值 6 ms），（A款）
- WUXGA （1920 x 1200）
- 记忆存储功能
- 触发输入和输出
- 坚固耐用的长FPC
- 全息摄影
- 波前校正
- 波束控制
- 生物传感
- 量子计算
- 脉冲/光束整形
- 可编程相位模式
规格
| Item | min | max | Units | Notes |
|---|---|---|---|---|
| Wavelength range | Type A：400 Type B：750 Type C：450 |
TypeA: 700 TypeB: 1100 TypeC: 1600 |
nm | TypeA: AR coating options: -00, -01, -12 TypeB: AR coating options: -00, -02, -03 TypeC: AR coating options: -00, -04, -14, -21 |
| Phase depth | 2π | – | rad. | TypeA: At 700 nm TypeB: At 1100 nm TypeC: At 1600 nm |
| Response time 1) Tr / Tf |
TypeA: 6 / 18 TypeB: 17 / 53 TypeC: 48 / 200 |
ms | ||
| Frame rate | 60 or 120 | Hz | Factory setting, default 60 Hz | |
| Panel reflectivity 2) | Typ. >70@532 nm | % | ||
| Aperture ratio | 95 | % | ||
| Pixel size / pitch | 7.8 / 8.0 | μm | ||
| Panel size | (H) 15.36 x (V) 9.60 | mm | Active area | |
| Panel resolution 3) | (H) 1920 x (V) 1200 | pixel | ||
| LCOS drive frequency | 1200 | Hz | ||
| Phase stability | Typ. < 0.002π | rad. | ||
| Gray level | 10 (1024 levels) | bit | ||
| Optical power handling 4) | Typ. 10 | W/cm² | 1550 nm CW, 2.0 mm beam diameter | |
| Operating temperature | 15 | 35 | ℃ | No condensation |
| Storage temperature | 0 | 40 | ℃ | No condensation |
| Interface | DVI*/ USB 3.0 | – | *10-bit using RGB 8-bit, 3 colors | |
| Dimensions | 117.6 x 117.6 x 33.7 | mm | ||
| Control software | GUI software and SDK for Windows | – | C#, Python, Matlab, Labview | |
1) Response time is a typical value and is not affected by frame rate.
Tr: Rise time between 10% and 90% levels in a phase change of 0 to 1023 bit (2π rad.) at 25℃.
Tf: Fall time between 90% and 10% levels in a phase change of 1023 to 0 bit (2π rad.) at 25℃.
2) Zero-order reflection. Depending on specified wavelength range.
3) Specification on the defect pixels are no object.
4) The value is not guaranteed.Depending on the conditions of the laser oscillator used, the product's life may be
< AR coating option >
| Item | -00 | -01 | -02 | -03 | -04 | -12 | -14 | -21 | Unit |
|---|---|---|---|---|---|---|---|---|---|
| Wavelength range 5) | no coating | 450-550 | 750-850 | 1000-1100 | 1500-1600 | 400-700 | 450-550 / 1500-1600 | 450-1600 | nm |
| AR coating reflectance 6) | 4 | < 0.5 | < 0.5 | < 0.5 | < 0.5 | < 1.5 | < 0.6 | < 2.5 | % |
5) We support custom AR coating request. Please contact us for detail.
6) Angle of incidence = 0 degree
视频
下载
论文
使用本公司SLM的论文
Dynamically patterning x-ray beam by a femtosecond optical laser
Published on: November 2024
Authors: Kenji Tamasaku, Takahiro Sato, Taito Osaka, Hitoshi Osawa, Diling Zhu, Tetsuya Ishikawa.
Publication: Science Advances
Issue/Year: Science Advances, Vol 10, Issue 47, 2024
DOI: 10.1126/sciadv.adp5326
Scan-less hyperspectral dual-comb single-pixel-imaging in both amplitude and phase
Published on: September 2017
Authors: Kyuki Shibuya, Takeo Minamikawa, Yasuhiro Mizutani, Hirotsugu Yamamoto, Kaoru Minoshima, Takeshi Yasui, and Tetsuo Iwata
Publication: Optics Express
Issue/Year: Optics Express Vol. 25, Issue 18, pp. 21947-21957 (2017)
DOI: 10.1364/OE.25.021947
Multiwavelength three-dimensional microscopy with spatially incoherent light, based on computational coherent superposition
Published on: May 2020
Authors: Tatsuki Tahara, Tomoyoshi Ito, Yasuyuki Ichihashi, and Ryutaro Oi
Publication:Optics Letters
Issue/Year: Optics Letters Vol. 45, Issue 9, pp. 2482-2485 (2020)
DOI: 10.1364/OL.386264
Quantum Airy photons
Published on: August 2018
Authors: Stephanie Maruca, Santosh Kumar, Yong Meng Sua, Jia-Yang Chen, Amin Shahverdi and Yu-Ping Huang
Publication: Journal of Physics B
Issue/Year: Journal of Physics B: Atomic, Molecular and Optical Physics, Volume 51, Number 17
DOI: 10.1088/1361-6455/aacac5
Spatial mode demultiplexing technique using angularly multiplexed volume holograms with a phase plate
Published on: August 2017
Authors: Shimpei Shimizu, Atsushi Okamoto, Fumiya Mizukawa, Kazuhisa Ogawa, Akihisa Tomita, Taketoshi Takahata, Satoshi Shinada and Naoya Wada
Publication: Japanese Journal of Applied Physics
Issue/Year: 2017 The Japan Society of Applied Physics Japanese Journal of Applied Physics, Volume 56, Number 9S
DOI: 10.7567/JJAP.56.09NA05
Orbital Angular Momentum-based Space Division Multiplexing for High-capacity Underwater Optical Communications
Published on:September 2016
Authors: Yongxiong Ren, Long Li, Zhe Wang, Seyedeh Mahsa Kamali, Ehsan Arbabi, Amir Arbabi, Zhe Zhao, Guodong Xie, Yinwen Cao, Nisar Ahmed, Yan Yan, Cong Liu, Asher J Willner, Solyman Ashrafi, Moshe Tur, Andrei Faraon, Alan E Willner
Publication: Scientific Reports
Issue/Year: Sci Rep. 2016 Sep 12;6:33306.
DOI: 10.1038/srep33306
Dynamic characterization of polarization property in liquid-crystal-on-silicon spatial light modulator using dual-comb spectroscopic polarimetry
Published on: August 2020
Authors: Hidenori Koresawa, Marc Gouryeb, Kyuki Shibuya, Takahiko Mizuno, Eiji Hase, Yu Tokizane, Ryo Oe, Takeo Minamikawa, and Takeshi Yasui
Publication: Optics Express
Issue/Year: Optics Express Vol. 28, Issue 16, pp. 23584-23593 (2020)
DOI: 10.1364/OE.399200
Holographic ultraviolet nanosecond laser processing using adaptive optics
Published on:March 2023
Authors: Satoshi Hasegawa, Mizuki Kato & Yoshio Hayasaki
Publication: Applied Physics B
Issue/Year: Appl. Phys. B 129, 52 (2023)
DOI: 10.1007/s00340-023-07993-1
